4G LTE network trail camera NFC connection APP remote control
| Specification | |
|
Day/Night Mode |
Yes |
|
IR Range |
20m |
|
IR Setting |
54pcs; 940nm-IR LED |
|
Memory |
SD Card (8GB – 32GB) |
|
Operating Keys |
4 |
|
Lens |
F/2.0; DFOV=60°; Auto IR-Cut-Remove (at night) |
|
PIR Angle |
60° |
|
PIR Distance |
20m |
|
Picture Size |
SD Card：5MP/8MP/12MP = 3072x1728/3840x2160/4608x2592 |
|
Send：Thumbnail(640x360) / HD Photo(3MP-Upon Request) |
|
|
Shooting Numbers |
1P/2P/3P |
|
Picture Format |
.JPG |
|
Video Resolution |
SD Card：1080P = 1920x1080 |
|
Send：Thumbnail video(CVGA-512x288) / HD Video(1080P-Upon Request) |
|
|
Live Stream：720P(1280x720) |
|
|
Video Length |
SD Card：10sec. |
|
Send：Thumbnail video-3s / Original Video-10s |
|
|
Live Stream：Max 10min/view |
|
|
Video Format |
.MP4 |
|
Trigger Time |
0.5~0.6s |
|
Trigger Interval |
25s~30s(Send) |
|
Camera + Video |
Yes |
|
Time Lapse |
Yes |
|
GPS |
Yes |
|
SD Card Cycle |
ON/OFF |
|
Battery Type |
12AA，12V |
|
External DC |
12V-2A |
|
Stand-by Current |
0.165mA |
|
Stand-by Time |
6~8 months |
|
Auto Power Off |
In Setup mode, camera will automatically power off in 3 mins if there is no keypad touching. |
|
Wireless Module |
LTE Cat1 module; 2G & 3G networks are also supported in some countries. |
|
NFC; Sensing distance of about 1cm |
|
|
Interface |
Type-C/DC Port/SIM Card/SD Card |
|
APP |
“Trailcam Ace” Support Android/IOS system |
|
Fittings |
Standard：Antenna; Strap; Instruction Book Optional：Solar Panel; Lithium Battery Box |
|
Operating Temperature |
-20°C to 60°C |
|
Storage Temperature |
-25°C to 65°C |
|
Operation Humidity |
5%-90% |
|
Waterproof Spec |
IP66 |
|
Dimensions |
140.0*110.0*90.0 mm |
|
Weight |
425.0 g |
|
Certification |
CE FCC RoHs |
